Box Type Condenser for Energy-saving Water Chiller/Heater
1.Kitdoo air cooled condensers are reasonable structure good compatibility and can be matched with various compressors.
2.The shell is made of quality steel with surface plastic-sprayed which is corrosion-resistant and beautiful
3.According to customer’s requirement different condenser fans are available
|
Model |
Capacity
（w） |
Cooling surface
(m2) |
Dimension
(mm) |
Fan quantity |
fan size
(mm) |
|
FNF-7.2/26 |
7800 |
26 |
820*165*430 |
2 |
350 |
|
FNF-8.8/30 |
8800 |
30 |
950*180*610 |
2 |
400 |
|
FNF-9.0/42 |
10800 |
42 |
980*200*590 |
2 |
400 |
|
FNF-10.2/50 |
14000 |
50 |
950*200*530 |
2 |
400 |
|
FNF-15.2/53 |
15200 |
53 |
980*200*590 |
2 |
400 |
|
FNF-19/63 |
19000 |
63 |
960*200*630 |
2 |
400 |
|
FNF-21.5/75 |
22000 |
75 |
960*220*630 |
2 |
400 |
